Aruba 6300F 48-port 1GbE Class 4 PoE and 4-port SFP56 Switch JL665A

    • 48x ports 10/100/1000BaseT PoE+ ports supporting up to 30W per port. Model JL665A.
    • 4x 1/10/25G SFP ports (50G capability for use with 50GbE DACs for interconnect and VSF stacking)
    • Internal (fixed) power supply (950W), fixed fans
    • Up to 720W of PoE+
    • Dimensions: (H) 4.39 cm x (W) 44.2 cm x (D) 32.7 cm (1.73″ x 17.4″ x 12.9″)
    • Weight: 5.10 kg (11.24 lbs)

  • 720W of Class 4: JL665A
  • Management ports
    • 1x USB-C Console Port
    • 1x OOBM port
    • 1x USB Type A Host port
    • 1x Bluetooth dongle for use with Aruba CX Mobile App


Electrical characteristics
  • Frequency range: 50-60 Hz
  • AC Voltage: 100-240 volts
  • Maximum current range: 12A – 1.2A
